Applications of directional liquid transport on rigid CMIA. (IMAGE)

The Hong Kong Polytechnic University

Applications of directional liquid transport on rigid CMIA.

Caption

(A and B) Ethanol is transported continuously and directionally on CMIA along complex paths: (A) a zigzag pattern and (B) a cartoon house pattern. (C) CMIA serves as a functional three-way valve. The first row of images shows CMIA structures of inlet I, inlet II, and outlet III. In states I and II, the liquid (ethanol dyed red) deposited on either inlet I or inlet II can be transported to outlet III, respectively. In state III, the liquid (ethanol dyed blue and yellow, respectively) is deposited on both inlets I and II and can flow along designed paths, then be mixed to a green color and flow out from outlet III. The liquid depositing flow rate is 2.2 μL/s.

Credit

© 2024 Research and Innovation Office, The Hong Kong Polytechnic University. All Rights Reserved.
