Measurement result of an asphere. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Measurement result of an asphere.

Caption

Measurement result of an aspheric shaped specimen measured with the novel Tilted Wave Fizeau Interferometer. The deviation from the nominal design surface shape is shown. The specimen shows three markers at the lower rim of the surface. These are three Gaussian shaped dips that nicely illustrate the high lateral and height resolution of the method.

Credit

by Christian Schober, Rolf Beisswanger, Antonia Gronle, Christof Pruss, Wolfgang Osten

Usage Restrictions

Credit must be given to the creator.

License

CC BY
