Miniaturized High-Performance Filter Capacitor Based on Structurally Integrated Carbon Tube Grids (IMAGE)

Hefei Institutes of Physical Science, Chinese Academy of Sciences

Miniaturized High-Performance Filter Capacitor Based on Structurally Integrated Carbon Tube Grids

Caption

Figure 2. Assembly structure and electrochemical performances of the 3D-CT grid-based EDLCs. (A) Schematic of EDLC assembly structure. (B) Complex plane plot of the 3D-CT based EDLCs. (C) Phase angle versus frequency of 3D-CT-10, 3D-CNT@CT-10, 3D-RCT-10, 3D-RCT-12, and commercial AEC (Panasonic, Japan, 6.3 V/330 µF). (D) Comparison of the areal capacitance at 120 Hz of 3D-CT-10, 3D-CNT@C-10, 3D-RCT-10(12), and other reported EDLCs used in the AC filter circuits with the phase angle near or less than -80o.

Credit

HAN Fangming

Usage Restrictions

no

License

Original content
