New materials could slash energy costs for CO2 capture

HOUSTON -- (May 30, 2012) -- A detailed analysis of more than 4 million absorbent minerals has determined that new materials could help electricity producers slash as much as 30 percent of the "parasitic energy" costs associated with removing carbon dioxide from power plant emissions.

The research by scientists at Rice University, the University of California, Berkeley, Lawrence Berkeley National Laboratory (LBNL) and the Electric Power Research Institute (EPRI) was published online this week in the journal Nature Materials.

Coal- and natural-gas-fired power plants account for about half of the carbon dioxide (CO₂) that humans add to the atmosphere each year, but current technology for capturing that CO₂ and storing it underground can gobble up as much as one-third of the steam the plant could otherwise use to make electricity.

In the new study, researchers found that commonly used industrial minerals called zeolites could significantly improve the energy efficiency of "carbon capture" technology.

"It looks like we can beat the current state-of-the-art technology by about 30 percent, and not just with one or two zeolites," said study co-author Michael Deem, Rice's John W. Cox Professor of Bioengineering and professor of physics and astronomy. "Our analysis showed that dozens of zeolites are more efficient than the amine absorbents currently used for CO₂ capture."

Commercial power plants do not capture CO₂ on a large scale, but the technology has been tested at pilot plants. At test plants, flue gases are funneled through a bath of ammonia-like chemicals called amines. The amines are then boiled to release the captured CO₂, and additional energy is required to compress the CO₂ so it can be pumped underground. The "parasitic energy" costs associated with current technology is high; up to one-third of the steam that could be used to generate electricity is siphoned off to boil the amines and liquefy the CO₂.

Deem said the new study is the first to compare the "parasitic energy" costs for a whole class of carbon-capture materials. The study found dozens of zeolites that could remove CO₂ from flue gas for a lower energy cost than amines could.

Zeolites are common minerals made mostly of silicon and oxygen. About 40 exist in nature, and there are about 160 man-made types. All zeolites are highly porous -- like microscopic Swiss cheese -- and the pore sizes and shapes vary depending upon how the silicon and oxygen atoms are arranged. The pores act like tiny reaction vessels that capture, sort and spur chemical reactions of various kinds, depending upon the size and shape of the pores. The chemical industry uses zeolites to refine gasoline and to make laundry detergent and many other products.

In 2007, Deem and colleagues used computers to calculate millions of atomic formulations for zeolites, and they have continued to add information to the resulting catalog, which contains about 4 million zeolite structures.

In the new study, the zeolite database was examined with a new computer model designed to identify candidates for CO₂ capture. The new model was created by a team led by co-author Berend Smit, UC Berkeley's Chancellor's Professor in the departments of chemical and biomolecular engineering and of chemistry and a faculty senior scientist at LBNL. Smit and his UC Berkeley group worked with study co-author Abhoyjit Bhown, a technical executive at EPRI, to establish the best criteria for a good carbon capture material. Focusing on the energy costs of capture, release and compression, they created a formula to calculate the energy consumption for any materials in the zeolite database.

Running the painstaking calculations to compare the CO₂-capture abilities of each zeolite would have taken approximately five years with standard central processing units (CPUs), so Smit and his colleagues at UC-Berkeley and LBNL created a new way to run the calculations on graphics processing units, or GPUs -- the processors used in PC graphics cards. Deem said the GPU technique cut the compute time to about one month, which made the project feasible.

Smit said, "Our database of carbon capture materials is going to be coupled to a model of a full plant design, so if we have a new material, we can immediately see whether this material makes sense for an actual design."

Study co-authors include graduate students Li-Chiang Lin and Joseph Swisher, both of UC Berkeley; Adam Berger of the EPRI; Richard Martin, Chris Rycroft and Maciej Haranczyk, all of LBNL's Computational Research Division; and postdoctoral fellows Jihan Kim and Kuldeep Jariwala of LBNL's Materials Science Division. This research was supported by the Department of Energy, the Advanced Research Projects Agency--Energy and EPRI's Office of Technology Innovation.

High-resolution images are available for download at:

http://news.rice.edu/wp-content/uploads/2012/05/0601_ZEOLITE_ArtLg.jpg
CAPTION: Artist Kelly Harvey evoked images of the sea and a coral reef to hint at the diversity and quantity of structures in Rice University's database of 4 million zeolite structures.
CREDIT: Kelly Harvey/Rice University

http://news.rice.edu/wp-content/uploads/2012/05/0601_ZEOLITE_TwoLg.jpg
CAPTION: This image depicts the carbon-capture characteristics of one zeolite structure. The arrangement of oxygen atoms (red) and silicon atoms (tan) influences the regions in the pores (colored surface) where CO₂ can be captured.
CREDIT: B. Smit/UC-Berkeley

A copy of the Nature Materials paper is available at: http://dx.doi.org/10.1038/NMAT3336
