image: Transmission electron microscope (TEM) image: atomically thin (monolayer) tin-sulfide nanosheet (scale bar is 500 nm) view more
Credit: FLEET
RMIT-UNSW collaboration applies liquid-metal synthesis to piezoelectrics, advancing future flexible, wearable electronics, and biosensors drawing their power from the body's movements.
Materials such as atomically-thin tin-monosulfide (SnS) are predicted to exhibit strong piezoelectric properties, converting mechanical forces or movement into electrical energy.
This property, along with their inherent flexibility, makes them likely candidates for developing flexible nanogenerators that could be used in wearable electronics or internal, self-powered biosensors.
However to date, this potential has been held back by limitations in synthesising large, highly crystalline monolayer tin-monosulfide (and other group IV monochalcogenides), with difficulties caused by strong interlayer coupling.
The new study resolves this issue by applying a new liquid-metal technique, developed at RMIT, to synthesise the materials.
Subsequent measurements confirm that tin-monosulfide synthesised using the new method displays excellent electronic and piezoelectric properties.
The resulting stable, flexible monolayer tin-monosulfide can be incorporated in a variety of devices for efficient energy harvesting.
The work started over two and a half years ago and strong collaborative work between RMIT and UNSW allowed its fruition. Ms Hareem Khan, the first author of the paper, showed remarkable perseverance to surmount many technical challenges to demonstrate the viability of the concept, with Prof Yongxiang Li.
LIQUID METAL SYNTHESIS
The unprecedented technique of synthesis used involves the van der Waals exfoliation of a tin sulphide (SnS), that is formed on the surface of tin when it is melted, while being exposed to the ambient of hydrogen sulfide (H2S) gas. H2S breaks down on the interface and sulfurises the surface of the melt to form SnS.
The technique is equally applicable to other monolayer group IV monochalcogenide, which are predicted to exhibit the same strong piezoelectricity.
This liquid metal based method allows us to extract homogenous and large scale monolayers of SnS with minimal grain boundaries.
Measurements confirm the material has high carrier mobility and piezoelectric coefficient, which translates into exceptional peak values of generated voltage and loading power for a particular applied strain, impressively higher than that any previously reported 2D nanogenerator.
High durability and flexibility of the devices are also demonstrated.
This is evidence that the very stable as-synthesised monolayer SnS can be commercially implemented into power-generating nanodevices.
They can also be used for developing transducers for harvesting mechanical human movements, in accordance to the current technological inclinations towards smart, portable and flexible electronics.
The results are a step towards piezoelectric-based, flexible, wearable energy-scavenging devices.
It also presents an unprecedented synthesis technique for large (wafer) scale tin-monosulfide monolayers.
PIEZOELECTRIC MATERIALS
Piezoelectric materials can convert applied mechanical force or strain into electrical energy.
Best known by name in the simple 'piezo' lighter used for gas BBQs and stovetops, piezo-electric devices sensing sudden changes in acceleration are used to trigger vehicle air bags, and more-sensitive devices recognise orientation changes in mobile phones, or form the basis of sound and pressure sensors.
Even more sensitive piezoelectric materials can take advantage of the small voltages generated by extremely small mechanical displacement, vibration, bending or stretching to power miniaturised devices, for example biosensors embedded in the human body, removing the need for an external power source.
THE STUDY
Liquid metal-based synthesis of high performance monolayer SnS piezoelectric nanogenerators was published in Nature Communications in July 2020 (DOI 10.1038/s41467-020-17296-0).
The study represents a collaboration between two Australian Research Council Centres of Excellence: the Centre for Exciton Science, and the Centre for Future Low-Energy Electronics Technologies (FLEET). ARC funding also comes from the Discovery Project, DECRA and ARC Laureate programs, and from the RMIT Vice-Chancellor Fellowship.
Facilities and advice from the Australian Microscopy & Microanalysis Research Facility (RMMF), RMIT Micro Nano Research Facility (MNRF) and the Centre for Advanced Solid and Liquid based Electronics and Optics (CASLEO) was critical to the success of the study, as was assistance from the CSIRO for PESA measurements.
###
