Overall schematics. (IMAGE)
Caption
(a) Schematic of the X-ray imaging system. (b) Bright-field and X-ray images of the standard X-ray resolution pattern plate with the Cs3MnBr5 NC-embedded glass. (c) MTF of X-ray images obtained from the Cs3MnBr5 NC-embedded glass (the thickness is 0.6 mm). (d) Photographs of a cylindrical ABS resin embedded with an iron spring in air (top) and in dimethyl silicone oil (bottom). (e) Thermal imaging photographs (top) and X-ray images (bottom) of the cylindrical ABS resin embedded with an iron spring immersed in dimethyl silicone oil at different temperatures. Scale bar, 1 cm. (f) RL intensity of Cs3MnBr5 NCs in the glass recorded over continuous 120 on/off cycles during 60 min. (g) Photograph (left) and X-ray images (right) of the chip taken under continuous irradiation for 2 h. Scale bars, 2 mm.
Credit
Le, Huang, et al. doi 10.1117/1.AP.5.4.046002.
