Figure 2. Reducing crosstalk noise between input/output (IO) lines (IMAGE)

Tokyo Institute of Technology

Figure 2. Reducing crosstalk noise between input/output (IO) lines

Caption

Adjacent IO lines are always out of phase with each other, meaning that they will never change their value at the same time. This reduces crosstalk noise between lines and makes the operation of the proposed architecture more robust.

Credit

Professor Takayuki Ohba

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.

License

CC BY-NC-ND
