Tokamak geometry (IMAGE)

National Research Council of Science & Technology

Tokamak geometry

Caption

Plasma configuration of a FIRE mode in Korea Superconducting Tokamak Advanced Research(KSTAR). The colour of lines indicates the ion temperature in keV, where 10 keV corresponds to ~120 million Kelvin.

Credit

Korea Institute of Fusion Energy (KFE)
