Scatter plot of the Young’s modulus of 92 viable IP-Dip-based cuboids in comparison to their corresponding DC value including a dashed line with = (9.52 DC – 0.56) GPa representing fitted data points from Bauer et al. (IMAGE)

SPIE--International Society for Optics and Photonics

Scatter plot of the Young’s modulus of 92 viable IP-Dip-based cuboids in comparison to their corresponding DC value including a dashed line with = (9.52 DC – 0.56) GPa representing fitted data points from Bauer et al.

Caption

Scatter plot of the Young’s modulus of 92 viable IP-Dip-based cuboids in comparison to their corresponding DC value including a dashed line with = (9.52 DC – 0.56) GPa representing fitted data points from Bauer et al. (a) and a scatter plot of the value of 68 viable IP-Q-based cuboids (b) in comparison with their corresponding DC. The indentation measurements of the IP-Q and IP-Dip samples have a relative standard deviation averaged to 2.5% and 3.7%, respectively.

Credit

The Authors doi: 10.1117/1.JOM.2.3.033501
