Flow Battery Diagrams

Caption

These diagrams compare Stanford/SLAC's new lithium-polysulfide flow battery design with conventional "redox" flow batteries. The new flow battery uses only one tank and pump and uses a simple coating instead of an expensive membrane to separate the anode and cathode.

Credit

Greg Stewart, SLAC National Accelerator Laboratory

Usage Restrictions

Please provide credit if possible.
