Nano Color Sorter

Caption

This scanning electron image of a nano color sorter with the vertical bowtie antenna shifted 5 nanometers (nm) to the left of center. In (a) the bowtie has been exited at 820 nm and in (b) at 780 nm. The two modes are spectrally and spatially distinct while maintaining nanoscale mode volumes.

Credit

James Schuck, Berkeley Lab Molecular Foundry

Usage Restrictions

None
