Transistor Cross Section (IMAGE)

DOE/Lawrence Berkeley National Laboratory

Transistor Cross Section

Caption

Transmission electron microscope image of a cross section of the transistor. It shows the ~ 1 nanometer carbon nanotube gate and the molybdenum disulfide semiconductor separated by zirconium dioxide which is an insulator.

Credit

Qingxiao Wang, UT Dallas

Usage Restrictions

All rights reserved. Commercial use prohibited.
