Fig. 2 Conductivity of Nanowire Arrays under Random and Ordered Orientation Configurations

Caption

This is a 2-D color map showing voltage at different nodes in computational domain for network arrays with concentration much higher than the percolation concentration (C?~?5 Cp). The dots represent voltages at each nodes. Left border voltage is 10?V, right border voltage is 0?V.

Credit

Tansu, Lehigh University
