Graphene Liquid Cell (IMAGE)

DOE/Lawrence Berkeley National Laboratory

Graphene Liquid Cell

Caption

In the graphene liquid cell, opposing graphene sheets form a sealed liquid nanoscale reaction chamber that is transparent to an electron microscope beam. The cell allows nanocrystal growth, dynamics and coalescence to be captured in real time at atomic resolution via a transmission electron microscope.

Credit

Lawrence Berkeley National Laboratory

Usage Restrictions

None
