Photonic Chip (2 of 3) (IMAGE)

University of California - Berkeley

Photonic Chip (2 of 3)

Caption

This is a raw, high-resolution photo of the chip, with all chip electrical and photonic features clearly visible. Photo taken under microscope at the UC Berkeley Marvell Nanofabrication Laboratory.

Credit

Image by Chen Sun, sunchen@eecs.berkeley.edu, with help from Sangyoon Han, sangyoon@eecs.berkeley.edu

Usage Restrictions

image must include credit to UC Berkeley ["Chen Sun/UC Berkeley"]. The image cannot be used to promote a product or attempt to commercialize the university.

License

Licensed content
