Figure 2 (IMAGE)

Moscow Institute of Physics and Technology

Figure 2

Caption

Gold films (Au) of varying thickness -- indicated in nanometers (nm) -- deposited on the conventionally used silicon dioxide substrate (SiO?, bottom row) and a molybdenum disulfide monolayer (MoS?, top row), as seen with an electron microscope

Credit

Yury Stebunov <em>et al</em>.

Usage Restrictions

None
