Simulated absorption distribution for the sensitized ternary OPV cells with different semiconductor layer thickness. (IMAGE)

Hiroshima University

Simulated absorption distribution for the sensitized ternary OPV cells with different semiconductor layer thickness.

Caption

(a) ~100 nm thickness, (b) ~400 nm thickness. ITIC has three "absorption spots" when the semiconductor layer (PTzBT/PCBM/ITIC) is thick while it has only one when the layer is thin. This originates in the enhanced optical interference.

Credit

Itaru Osaka, Hiroshima University

Usage Restrictions

News organizations may use or redistribute this image, with proper attribution, as part of news coverage of this paper only.
