Microscope Images of Lithium Metal Anodes

Caption

Microscope images of lithium metal anodes after 500 charge/discharge cycles in tests at Rice University show the growth of dendrites is quenched in the anode at left, protected by a film of carbon nanotubes. The unprotected lithium metal anode at right shows evidence of dendrite growth.

Credit

Tour Group/Rice University

Usage Restrictions

Credit must be used.
