Droplet Figure

Caption

A graphic of now the new droplet-based electrical hotspot cooling system works. Heat vaporizes water trapped in a sponge-like layer and the vapor droplets carry away heat. The vapor then coalesces on a cooled super-hydrophobic floor, jumping back up beneath hotspots when they become large enough.

Credit

Chuan-Hua Chen, Duke University
