Variety of 3-D Printed Honeycomb Structures

Caption

Left: Optical images of square, hexagonal, and triangular honeycomb structures composed of SiC-filled epoxy. Scale bars are 2 mm. Center and right: Optical images of a triangular honeycomb structure composed of SiC/C-filled epoxy, which reveal clear evidence of highly aligned carbon fibers oriented along the print direction. The scale bars are 500 μm.

Credit

Images courtesy of Brett G. Compton, Harvard University.
