Pristine/ Charged State/ Discharged State

Caption

Cross-sectional SEM images of graphite composite electrodes: (a) pristine, (b) at charged state with a capacity of 250 mA h g-1, and (c) at a discharged state with a capacity of 250 mA h g-1. TEM images of graphite powder (d) before and (e) after the first galvanostatic charge-discharge cycle at a capacity of 250 mA h g-1. Insets: selected area electron diffraction (SAED) patterns.

Credit

Masahiro Shimizu, Shinshu University

Usage Restrictions

The image may only be used with appropriate caption or credit.

License

Original content
