Optical Transmission

Caption

The new display optically transforms the object display volume generated from the multifocal display into the projection volume for integral imaging by automatically mapping the rays through a microlens array (optical pickup). The transformed information can be enlarged to the large screen through a projection lens. After the projection, the object display volume is reconstructed, passing through another lens array in a similar manner to the existing integral imaging system.

Credit

Byoungho Lee, Seoul National University
