Flood Visualization

Caption

Pictured here is a visualization of the team's flood wave propagation simulation for the Saylorville Dam break case, shown at 9000 seconds. The blue lines indicate the position of the main channel of the Des Moines River, and the black and green lines indicate the position of the two main tributaries: Beaver Creek and Raccoon River, respectively.

Credit

Iowa Flood Center

Usage Restrictions

Must use credit.
