Lattice structure as seen by X-ray tomography

Caption

Following the example of avian bones, intricate lattice structures inside of hollow turbine buckets provide the necessary stability. 3D-image of the lattice structure reconstructed from x-ray tomography data.

Credit

Dr. Tobias Fritsch / BAM
