Detonation of a thin explosive film with a barrier

Caption

An image from a test detonation at Sandia National Laboratories of a thin explosive film with a 3/8th inch tall thunderbird-shaped barrier. The "shimmering" lines to the right of the thunderbird are the shock waves from the explosion, detected by schlieren imaging, a technique that can detect differences in air density.

Credit

Sandia National Laboratories

Usage Restrictions

Credit Sandia National Laboratories
