2. Conceptual & Schematic diagram (IMAGE)

National Research Council of Science & Technology

2. Conceptual & Schematic diagram

Caption

(1) 0.1 MWth Oxy-CFBC facility configuration: Feeding system of fuel and limestone for de-SOx, CFB combustor, Cyclone, loop seal, external heat exchanger, Heat exchangers, Flue gas recirculation unit, Bag filter for fine particle capture, Water recovery unit (FGC, Membrane), De-NOx unit (SNCR, SCR). (2) Competitive edge & differentiation: Development of design and operation technology for FEPCRC's own Oxy-CFBC plant ? Reduce the amount of flue gas by 80% compared to the air combustion, Combustion efficiency increases by2 % compared to the air combustion, Available to separate CO2 over 90%

Credit

Korea Institute of Energy Research (KIER)

Usage Restrictions

The sources of photos and research results from KIER must be specified.
