experimental setup for the imaging of magnetic structures (IMAGE)

Johannes Gutenberg Universitaet Mainz

experimental setup for the imaging of magnetic structures

Caption

Experimental setup for the imaging of magnetic structures using simultaneous magneto-optic Kerr effect (MOKE) microscopy and wide-field diamond magnetometry

Credit

photo/©: Arne Wickenbrock, JGU

Usage Restrictions

This image may only be used in connection with the press release "Combined technique using diamond probes for nanoscale imaging of magnetic vortex structure", issued by Johannes Gutenberg University Mainz on March 9, 2021.
