BGA Trap

Caption

A photograph of the completed BGA trap assembly. The trap chip is at the center, sitting atop the larger interposer chip that fans out the wiring. The trap chip surface area is 1mm x 3mm, while the interposer is roughly 1 cm square.

Credit

D. Youngner, Honeywell

Usage Restrictions

This image may be used only with appropriate caption and credit.
