Acousto-electric Chip with Inset (IMAGE)

DOE/Sandia National Laboratories

Acousto-electric Chip with Inset

Caption

An acousto-electric chip, top, produced at Sandia National Laboratories includes a radio-frequency amplifier, circulator and filter. An image taken by scanning electron microscopy shows details of the amplifier.

Credit

Photo by Bret Latter. Microscopy image courtesy of Matt Eichenfield

Usage Restrictions

None
