Photograph of a Prototype Mixer

Caption

This is a photograph of a prototype mixer (with 3-mm wide channels) that can be downscaled for microfluidic applications. Mixing of blue and yellow liquids was by a paddle attached to the middle of a carbon nanotube yarn that was half immersed in electrolyte and rotated in opposite directions by alternately applying 0 V and -3 V to the yarn. (B, C) Close up photographs of the paddle and surrounding liquid before and during mixing, respectively.

Credit

Image courtesy of the University of Texas at Dallas

Usage Restrictions

None
