Figure 2 (IMAGE)

Moscow Institute of Physics and Technology

Figure 2

Caption

Two ways for feeding crystals into the operating area of the device: in a stream of liquid (3, left) and on a solid substrate (3, right). In both cases, the X-ray beam (2) passing through crystals generates a diffraction pattern on the screen (1).

Credit

Elena Khavina/MIPT Press Office

Usage Restrictions

None
