Screenshot of CAD Layout for the Circuit and Photograph of Circuit Board (IMAGE)

Tokyo Institute of Technology

Screenshot of CAD Layout for the Circuit and Photograph of Circuit Board

Caption

The integrated circuit was designed as a tiny "cell" about 200-100 μm large (left), and its first prototype was accommodated on a test board providing all necessary support functions (right).

Credit

Hiroyuki Ito and Ludovico Minati

Usage Restrictions

None

License

Licensed content
