Conventional microscope Vs Phonon probe (IMAGE)

University of Nottingham

Conventional microscope Vs Phonon probe

Caption

(top) Conventional microscope pictures of model biological cells. (bottom) The phonon probe reproduces 3D images of the objects (colour is height). Simultaneously, the probe detected stiffness related measurements which are mapped in green on the top left image. The white scales bar are 10 micrometres long.

Credit

Dr Salvatore La Cavera

Usage Restrictions

None
