Convention Versus Monocentric Lens

Caption

This is the advantages of a monocentric lens. Top: This image was captured with a conventional wide-angle lens, a Canon EOS 5D Mark III DSLR with a 12mm focal length. Middle: An inset of the image above. A close-up (right) of the man holding the board shows that this picture, taken with a conventional wide-angle camera with 12mm focal length, does not have very high resolution. Bottom: An image taken with a monocentric lens relayed onto a high-magnification digital microscope. This system did not include the fiber coupling developed by the researchers for their prototype camera, but the clarity of the detail shows the potential of using monocentric lenses to take images with both high resolution and a wide field of view.

Credit

Credit: UCSD Jacobs School of Engineering

Usage Restrictions

Must include caption and credit.
