Fig. 2 The schematic illustration of the 1st- and 2nd-order relaxations. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Fig. 2 The schematic illustration of the 1st- and 2nd-order relaxations.

Caption

Fig. 2 The schematic illustration of the 1st- and 2nd-order relaxations. Each of the two resonance modes(Ⅰ: Magnetic resonance, Ⅱ: Electric resonance) has two distinct states, that is, reflections upon the upper and lower interfaces. The two states can be vividly analogous to the two wells in the double-well model and enable the 1st-order relaxation process under each resonance modes. Furthermore, the two resonance modes (at f1 and f2) again form a 2nd-order relaxation process, which spans a much wider frequency band compared with that of the 1st-order relaxation processes. By modifying the 2nd-order relaxation process induced by two resonances, the phase variation between f1 and f2 can be controlled, enabling dispersion engineering.

Credit

by Xinmin Fu, Yajuan Han, et al.

Usage Restrictions

Credit must be given to the creator.

License

CC BY
