FIG 3 (IMAGE)
Caption
Fig. 3 | Gain profiles of the metalens antenna when the feed is placed on the focal plane with different displacements x. Comparison between the experimental results (blue lines) and simulation results (red lines) when the feed source position is (a) at x = 0, showing a maximum gain of 21.7 dBi, which corresponds to an angle of 0°; (b) at x = 15 mm, showing a maximum gain is 21.2 dBi, which corresponds to an angle of 25°; (c) at x = 30 mm, showing a maximum gain is 18.3 dBi, which corresponds to an angle of 55°. (d) The relationship between the maximum gain angles and the corresponding gains obtained from testing the feed source at different positions. Inset shows the sample photo and unit cell structure diagram.
Credit
OES
Usage Restrictions
Credit must be given to the creator.
License
CC BY
