SEM images of the PDMS microstructured electrodes (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

SEM images of the PDMS microstructured electrodes

Caption

SEM images of the PDMS microstructured electrodes. a–c, SEM images of underexposed, normally exposed, and overexposed microstructured electrodes at the same one-dimensional speckle size of σ1 = 2.5 μm. Insets show the magnified SEM images. d–f, SEM images of overexposed microstructured electrodes at σ2 = 5 μm, σ3 = 10 μm, and σ4 = 15 μm.

Credit

by Yong Zhou, Kun Wang, Junkun Mao, Yifei Ma, Mei Wang, Suotang Jia, Xuyuan Chen, and Zhaomin Tong

Usage Restrictions

Credit must be given to the creator.

License

CC BY
