Fig. 2. AOIs of the Space Raman Spectrometer (A, Space Raman Spectrometer; B, power indicator; C, cleaning interface; D, liquid inlet interface; E, power interface; F, communications indication; G, communications interface; H, medical Luer joints for cle (IMAGE)

Beijing Institute of Technology Press Co., Ltd

Fig. 2. AOIs of the Space Raman Spectrometer (A, Space Raman Spectrometer; B, power indicator; C, cleaning interface; D, liquid inlet interface; E, power interface; F, communications indication; G, communications interface; H, medical Luer joints for cle

Caption

 Fig. 2. AOIs of the Space Raman Spectrometer (A, Space Raman Spectrometer; B, power indicator; C, cleaning interface; D, liquid inlet interface; E, power interface; F, communications indication; G, communications interface; H, medical Luer joints for cleaning; I, medical Luer joints for liquid intake; J, LEMO low voltage connector plug; K, EGN.2M.310.XLM communications connector plug).

Credit

Space: Science & Technology

Usage Restrictions

News organizations may use or redistribute this image, with proper attribution, as part of news coverage of this paper only

License

Licensed content
