Figure 3 | Simulated and experimental results for Sample 1 and Sample 2. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 3 | Simulated and experimental results for Sample 1 and Sample 2.

Caption

a-d Simulated results of the holographic images and diffraction patterns. e-h Experimental results of the holographic images and diffraction patterns. The blue and red arrows represent the polarization state of the incident and transmitted light respectively. Both the holographic images are reconstructed at a distance of 800 μm away from the samples. The diffraction patterns are calculated and captured in the far-field. The wavelengths of incident light for Sample 1 and Sample 2 are 540 nm and 800 nm respectively.

Credit

by Chi Xu, Ruizhe Zhao, Xue Zhang, Shifei Zhang, Xin Li, Guangzhou Geng, Junjie Li, Xiaowei Li, Yongtian Wang, Lingling Huang

Usage Restrictions

Credit must be given to the creator.

License

CC BY
