Figure 2. Compact phased-array transmitter with on-chip antennas (IMAGE)

Tokyo Institute of Technology

Figure 2. Compact phased-array transmitter with on-chip antennas

Caption

Thanks to a highly optimized circuit topology and layout, the proposed transmitter chips can be arranged into a 64-element array occupying a minuscule volume.

Credit

IEEE 2024

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.

License

CC BY-NC-ND
