Lithium-Ion Battery

Caption

In a lithium-ion battery, the lithium is stored in metallic (uncharged) form inside the particles of a graphic electrode. During discharge the lithium comes to the electrode’s surface, where it is ionized, creating a current that travels to the cathode. At the cathode, typically a lithium-based alloy, the ions are neutralized and enter electrode particles as metallic lithium. The battery is recharged by forcing a current to flow in the opposite direction, moving the lithium back into the anode.

Credit

MAPLE Lab/WUSTL

Usage Restrictions

pleae credit
