Graphs (IMAGE)

Stanford Woods Institute for the Environment

Graphs

Caption

Graphs showing timeline of energy sources for meeting all U.S. energy needs with wind, water and solar (WWS) power sources. The graph on left shows mix for 80% WWS by 2030 and 100% by 2035. The graph on right shows mix for is 80% by 2030 and 100% by 2050. The 2050 end points in both cases are cases examined in the study.

Credit

Jacobson, et al. / Renewable Energy

Usage Restrictions

Credit must be given to the creator. No derivatives or adaptations of the work are permitted.

License

CC BY-ND
