SEM of 3-D Nanomagnetic Logic Gate (IMAGE)

Technical University of Munich (TUM)

SEM of 3-D Nanomagnetic Logic Gate

Caption

This image shows scanning electron micrographs of a 3-D majority logic gate showing the scale of the computing area ,with dimensions less than 200 nanometers, and, in cross-section, the lower position of the third input magnet.

Credit

I. Eichwald/TUM

Usage Restrictions

This image may be freely used, with copyright noted, in news coverage of TUM.
