Temperature Dependent Phase Diagram of Ni1.9pt0.1mnga Magnetic Shape Memory Alloy

Caption

Temperature dependent phase diagram of Ni1.9Pt0.1MnGa magnetic shape memory alloy. Unit cells for different crystallographic phases (austenite, premartensite and martensite) are also shown. The T1 phase has 3M modulated structure with preserved cubic symmetry while T2 phase has 3M modulated structure with orthorhombic symmetry (Bain distorted phase).
