Exploded View of the CubeSat-Class Instrument (IMAGE)

NASA/Goddard Space Flight Center

Exploded View of the CubeSat-Class Instrument

Caption

This is an exploded view of the CubeSat-class 50-millimeter (2-inch) imaging instrument that technologist Jason Budinoff is manufacturing with 3-D-printed parts. It shows the mirrors and integrated optical-mechanical structures.

Credit

NASA Goddard/Jason Budinoff
