Configuration of a Resistive Storage Cell (IMAGE)

Helmholtz Association

Configuration of a Resistive Storage Cell

Caption

This shows the configuration of a resistive storage cell: An electric voltage is built up between the two electrodes so that the storage cells can be regarded as tiny batteries. Filaments formed by deposits during operation may modify the battery's properties.

Credit

Jülich Aachen Research Alliance (JARA)
