Directionality of the Coil-generated Magnetic Fields (IMAGE)

American Institute of Physics

Directionality of the Coil-generated Magnetic Fields

Caption

The directionality of the coil-generated magnetic fields is shown, along with the induced currents (influenced by the directional conductivity) when the transmitter coils for measuring the axial Z-directional conductivity (middle) and for measuring the X- and Y-directional conductivity (right) are energized.
