Schematic of MoS2 FET photodetector structure (IMAGE)

Advanced Devices & Instrumentation

Schematic of MoS2 FET photodetector structure

Caption

As a typical two-dimensional material, MoS2 exhibits unique optical and electrical properties due to its atomic thickness in the vertical dimension, making it a research hotspot in the field of optoelectronic detection. The performance of MoS2 devices highly depends on their material characteristics, device structures, and fabrication techniques.
